Storage Solutions: Capacity, Access, and Alignment Standards

PMC Storage Solutions covers wardrobes, kitchens, utilities, and full home storage from approved layout to handover. Scope includes content listing, volume calculation, hardware selection, and installation. Work proceeds against approved drawings with hold points at substrate and installation. Carcass in 18 mm BWP plywood. Shutter gap 3 mm. Alignment tolerance ±2 mm. Defects liability 12 months.

Capacity is fixed by content list and access frequency. Hanging depth 600 mm, shelf depth 450 mm. Drawer loads rated 30 kg for light items, 50 kg for clothes and cookware, 70 kg for pantry. Pull out trays load 20 kg each. Loft shelves load 40 kg per metre. All items documented in the approved itemised scope with quantities and rates. Handover occurs after snag closure, operation tests, and warranty documents are issued.

Our Execution Process

PMC Execution Sequence for Storage Projects

Step 1
1

Content and Access Audit

Content list prepared by type, size, weight, and frequency of use. Access zones defined: eye level 1200 mm to 1700 mm, mid zone 700 mm to 1200 mm, low zone 300 mm to 700 mm. Layout and itemised scope with quantities and rates approved in writing before procurement.

Step 2
2

Substrate and Service Check

Walls and floor checked for level and plumb within ±3 mm per 2 m. Load bearing verified for wall hung units: 60 kg per 600 mm run minimum. Services re-routed if conflict found. Concealment only after PMC inspection and photographic record.

Step 3
3

Fabrication and Hardware

Carcass in 18 mm BWP plywood. Shutters with 1.0 mm to 1.5 mm laminate or acrylic. Hinges 200,000 cycle tested. Drawer channels rated 30 kg, 50 kg, 70 kg per function. Pull out trays 450 mm depth, 20 kg load. Installation tolerance ±2 mm. Shutter gap 3 mm.

Step 4
4

Testing and Handover

All shutters and drawers operated 25 cycles. Alignment checked with feeler gauge. Loft shelves load tested to 40 kg per metre. Snag list closed with client sign-off. As-built drawings, hardware data sheets, and warranties issued at handover.

Service Inclusions

Scope Items for Storage Projects

Storage scope includes labour, materials, and management to deliver approved drawings to operational condition. Items not listed in the approved itemised scope with quantities and rates are excluded. All hardware and finishes are backed by test data or manufacturer data sheets.

Wardrobe

01. Wardrobe Systems

Depth 600 mm for hangers, 450 mm for shelves. Hanging rail height 1050 mm and 1900 mm. Drawer widths 450 mm to 900 mm. Shelf load 40 kg per metre. Hinge cup 35 mm.

Hidden Storage

02. Concealed Storage

Push to open or handle-less shutters with gap 3 mm. Toe kick 100 mm height. Skirting cut-out for air flow. End panels 18 mm with edge band 2 mm.

Kitchen Storage

03. Kitchen and Utility

Base units 560 mm deep. Tall units 600 mm deep. Drawers 500 mm deep with load 30 kg, 50 kg, 70 kg per function. Pull out pantry 200 mm to 300 mm wide.

Space-Saving Storage

04. Space Saving Units

Corner units with carousel 700 mm diameter, 20 kg per tray. Under stair drawers 800 mm depth, 30 kg load. Foldable iron board and ladder integrated where specified.

Multi-Use Storage

05. Multi Use Furniture

Bed with hydraulic lift rated 80 kg per side. Study table 1200 mm to 1500 mm wide, 600 mm deep, 750 mm height. Bench with storage 450 mm seat height.

Organized Setup

06. Organisation and Handover

Internal fittings by category: jewellery tray 50 mm depth, shoe rack 200 mm height per pair. Labels and dividers included. Snag closure record and warranties issued.

FAQs

Storage Solutions Questions

Answers cover capacity, loads, depths, and handover. For project specific queries, refer to the agreement.

Wardrobe hanging 600 mm. Shelf units 450 mm. Kitchen base units 560 mm. Wall units 350 mm. Pull out pantry 200 mm to 300 mm. Under stair drawers 800 mm.

Drawers rated 30 kg for light items, 50 kg for clothes and cookware, 70 kg for pantry. Shelves rated 40 kg per metre. Loft shelves 40 kg per metre. Pull out trays 20 kg each.

Substrate level and plumb ±3 mm per 2 m. Installation alignment ±2 mm. Shutter gap 3 mm. Hinge cup 35 mm. Toe kick height 100 mm. End panel edge band 2 mm.

Execution runs 20 to 35 days after layout freeze and material approval. Timeline depends on quantity, site readiness, and service routing.

Civil works, painting, false ceiling, lighting fixtures, and loose baskets or organisers are excluded unless listed in approved itemised scope with quantities and rates.
